背景：
搭建一个oracle镜像数据库,用于同步生产库数据,提供查询功能。
方案：
可使用的方案有有多种方式比如oracle adg,oracle goldengate以及DSG三种,如果镜像库不需要连接应用的话,采用adg方式比较合适。
ADG版本兼容
有关在异构平台搭建ADG的详细内容请参考文章：《在物理Data Guard 中对异构主备系统的支持(Doc ID 1602437.1)》
虽然这个案例需要跨平台，但从11g开始OracleDatabase支持有限制的跨平台配置DG，下面是配置异构平台DG的兼容性列表（物理Standby）：
1）从上面的兼容性列表可以看出，MicrosoftWindows (x86_64)(12)和Linux x86_64(13)能够兼容构建异构平台的DG，但需要注意的是OracleDatabase 需要是11g，并且需要应用Patch13104881，该Patch只存在于Linux平台，并且只在Windows（主库）向Linux（备库）同步时，需要在Linux平台应用此补丁（反向不会遇到相应的bug），更多内容请参考Patch13104881说明。
2）生产库和镜像库环境:(数据库软件版本必须一致,包括小版本)
环境：
生产库:
IP地址:10.10.10.10
操作系统:linux
数据库版本:oracle 11.2.0.3
实例名:cs
数据库名:cs
数据库db_unique_name:cs
镜像库:
IP地址:20.20.20.20
操作系统:windows server 2008
数据库版本:oracle 11.2.0.3
实例名:csb
数据库名:csb
数据库db_unique_name:csb
搭建步骤:
1.备份
为了避免手误或者疏忽弄坏数据库,开始动手之前先做备份,可使用expdp方式导出数据,同时正常关闭数据库,备份:spfile文件,controlfile文件
2.生产库进行以下配置
A.归档日志必须启用,并开启强制日志功能,添加standby日志组
startup mount;
alter database archivelog;
alter database force logging;
alter database add standby logfile group 4'/u01/app/oracle/oradata/standby04' size 100M;
alter database add standby logfile group 5'/u01/app/oracle/oradata/standby05' size 100M;
alter database add standby logfile group 6'/u01/app/oracle/oradata/standby06' size 100M;
alter database add standby logfile group 7'/u01/app/oracle/oradata/standby07' size 100M;
(日志文件大小设置和原redo文件一样,standby 尽量要比原redo数多一组)
B.创建pfile文件,并做以下修改
create pfile from spfile;
vim initcs (pfile文件的名称)
cs.__db_cache_size=8657043456
cs.__java_pool_size=67108864
cs.__large_pool_size=67108864
cs.__oracle_base='/u01/app/oracle'#ORACLE_BASE路径
cs.__pga_aggregate_target=21944598528
cs.__sga_target=12415139840
cs.__shared_io_pool_size=0
cs.__shared_pool_size=3288334336
cs.__streams_pool_size=134217728
*.audit_file_dest='/u01/app/oracle/admin/cs/adump'
*.audit_trail='db'
*.compatible='11.2.0.3.0'
*.control_files='/u01/app/oracle/oradatatest/cs/CONTROL01.ctl'#控制文件路径
*.db_block_size=8192
*.db_domain=''
*.db_file_name_convert='/u01/app/oracle/oradata','E:\app\Administrator\oradata\csb'
#生产库数据文件路径和镜像库数据文件路径,必须输入正确
*.db_name='cs'
*.db_unique_name='cs'
*.diagnostic_dest='/u01/app/oracle' #oracle_base路径
*.dispatchers='(PROTOCOL=TCP)(SERVICE=csXDB)'
*.fal_server='csb'
*.fal_client='cs'
*.log_archive_config='DG_CONFIG=(cs,csb)'
*.log_archive_dest_1='LOCATION=/u01/app/oracle/oradata/archivelogvalid_for=(all_logfiles,primary_role) db_unique_name=cs' #生产库归档路径,需要提前创建
*.log_archive_dest_2='SERVICE=csb lgwr syncvalid_for=(online_logfile,primary_role) db_unique_name=csb'
*.log_archive_dest_3='LOCATION=/u01/app/oracle/oradata/standbylogvalid_for=(standby_logfile,standby_role) db_unique_name=cs'#生产库standby路径,需要提前创建
*.log_archive_dest_state_3='defer'
*.log_file_name_convert='/u01/app/oracle/oradata','E:\app\Administrator\oradata\csb'#生产库redo文件路径和镜像库redo文件路径
*.memory_target=34359738368
*.open_cursors=300
*.processes=550
*.log_archive_format='%t_%s_%r.dbf'
*.remote_login_passwordfile='EXCLUSIVE'
*.undo_tablespace='UNDOTBS02'
*.standby_file_management='auto'
C.配置静态监听和tnsnames
[oracle@zhujianting-db1 admin]$ catlistener.ora
LISTENER =
(DESCRIPTION_LIST =
(DESCRIPTION =
(ADDRESS = (PROTOCOL = IPC)(KEY = EXTPROC1521))
(ADDRESS = (PROTOCOL = TCP)(HOST = zhujianting-db1)(PORT = 1521))
)
)
SID_LIST_LISTENER =
(SID_LIST =
(SID_DESC =
(GLOBAL_DBNAME = cs)
(ORACLE_HOME = /u01/app/oracle/product/11.2.0/dbhome_1)
(SID_NAME = cs)
)
)
Tnsname.ora文件
CS =
(DESCRIPTION =
(ADDRESS = (PROTOCOL = TCP)(HOST = 221.207.30.118)(PORT = 1521))
(CONNECT_DATA =
(SERVER = DEDICATED)
(SID=cs)
(SERVICE_NAME=cs)
)
)
CSB =
(DESCRIPTION =
(ADDRESS = (PROTOCOL = TCP)(HOST = 172.24.7.10)(PORT = 1521))
(CONNECT_DATA =
(SERVER = DEDICATED)
(SERVICE_NAME = csb)
)
)
3.镜像库操作步骤
A.安装好软件创建一个实例(此案例中为csb)
B.修改监听和tnsnames
listener.ora
SID_LIST_LISTENER =
(SID_LIST =
(SID_DESC =
(SID_NAME = csb)
(ORACLE_HOME = D:\app\Administrator\product\11.2.0.3\dbhome_1)
(SID_NAME = csb)
(ENVS ="EXTPROC_DLLS=ONLY:D:\app\Administrator\product\11.2.0.3\dbhome_1\bin\oraclr11.dll")
)
)
LISTENER =
(DESCRIPTION_LIST =
(DESCRIPTION =
(ADDRESS = (PROTOCOL = TCP)(HOST = WIN-PQO0LK35F91)(PORT = 1521))
)
)
配置tnsnames.ora文件
CS =
(DESCRIPTION =
(ADDRESS = (PROTOCOL = TCP)(HOST =10.10.10.10)(PORT = 1521))
(CONNECT_DATA =
(SERVER = DEDICATED)
(SID = cs)
(SERVICE_NAME = cs)
)
)
CSB =
(DESCRIPTION =
(ADDRESS = (PROTOCOL = TCP)(HOST =20.20.20.20)(PORT = 1521))
(CONNECT_DATA =
(SERVER = DEDICATED)
(SERVICE_NAME = csb)
)
)
C.复制生产库的pfile文件(文件名改为initcsb.ora),修改内容
cs.__db_cache_size=8657043456
cs.__java_pool_size=67108864
cs.__large_pool_size=67108864
cs.__oracle_base='D:\app\Administrator'#ORACLE_BASEset from environment
cs.__pga_aggregate_target=21944598528
cs.__sga_target=12415139840
cs.__shared_io_pool_size=0
cs.__shared_pool_size=3288334336
cs.__streams_pool_size=134217728
*.audit_file_dest='D:\app\Administrator\admin\csb\adump'
*.audit_trail='db'
*.compatible='11.2.0.3.0'
*.control_files='E:\app\Administrator\oradata\csb\CONTROL01.ctl'
*.db_block_size=8192
*.db_domain=''
*.db_file_name_convert='/u01/app/oracle/oradata','E:\app\Administrator\oradata\csb'
*.db_name='cs'
*.db_unique_name='csb'
*.diagnostic_dest='E:\app\Administrator'
*.dispatchers='(PROTOCOL=TCP)(SERVICE=csXDB)'
*.fal_server='cs'
*.fal_client='csb'
*.log_archive_config='DG_CONFIG=(cs,csb)'
*.log_archive_dest_1='LOCATION=E:\app\Administrator\oradata\csb\archivelogvalid_for=(all_logfiles,primary_role) db_unique_name=csb'
*.log_archive_dest_2='SERVICE=cs lgwr syncvalid_for=(online_logfile,primary_role) db_unique_name=cs'
*.log_archive_dest_3='LOCATION=E:\app\Administrator\oradata\csb\standbylogvalid_for=(standby_logfile,standby_role) db_unique_name=csb'
*.log_archive_dest_state_3='enable'
*.log_file_name_convert='/u01/app/oracle/oradata','E:\app\Administrator\oradata\csb'
*.memory_target=34359738368
*.open_cursors=300
*.processes=550
*.log_archive_format='%t_%s_%r.dbf'
*.remote_login_passwordfile='EXCLUSIVE'
*.undo_tablespace='UNDOTBS02'
*.standby_file_management='auto'
到此基本的文件参数配置以及完成,重新启动监听
4.生产库使用pfile文件启动,并创建spfile
startup pfile=’路径文件名’
create spfile from pfile=’路径文件名’;
镜像库使用pfile文件启动到nomount状态
startup nomount pfile=’路径文件名’;
create spfile from pfile=’路径文件名’;
5.开始数据库复制
rman target sys/oracle@csauxiliary sys/oracle@csb
duplicatetarget database for standby from active database;
这一个过程会持续很长时间,要有耐心(alter system archive log current)
6.等待数据库复制完成,登录镜像库
sqlplus sys/oracle@csb as sysdba
查看当前镜像库状态
select open_mode,database_role,db_unique_name from v$database;
OPEN_MODE DATABASE_ROLE DB_UNIQUE_NAME
-------------------- ---------------- ------------------------------
MOUNTED PHYSICAL STANDBY csb
启动数据库
alter database open;
再次查询镜像库状态
select open_mode,database_role,db_unique_name from v$database;
OPEN_MODE DATABASE_ROLE DB_UNIQUE_NAME
-------------------- ---------------- ------------------------------
READ ONLY PHYSICAL STANDBY csb
开启镜像库同步
alter database recover managed standbydatabase using current logfile disconnect from session;
查询镜像库状态,同步已经开启
select open_mode,database_role,db_unique_name from v$database;
OPEN_MODE DATABASE_ROLE DB_UNIQUE_NAME
-------------------- ---------------- ------------------------------
READ ONLY WITH APPLY PHYSICAL STANDBY csb
7、验证
可以查看生产库和主库归档文件序号是否一致
archive log list;
在生产库上插入数据或者创建测试表,在镜像库上查询是否同步过来.
