使用Spring Cloud Contract做异步消息契约测试

铁花盆的小世界 2021-06-21

299

This recipe introduce an example which do async messaging contract test by Spring Cloud Contract. There are two microservices in this example, EquipmentActivityService
and EquipmentCmdService
. EquipmentActivityService
send EquipmentInfo
to EquipmentCmdService
by Spring Cloud Stream and Kafka. Below is class for event payload.

@Data
public class EquipmentInfo {
    private String equipmentId;
    private String equipmentSize;
    private List<RtiEvent> events;
}


@Data
public class RtiEvent {
    private String operation;
    private String eventId;
    private String status;
}

In this example, EquipmentActivityService
is messaging producer and EquipmentCmdService
is messaging consummer. We can define an constract and do contract test for produer and consummer separately. If both sides pass the contract test, then we think these two mircoservices can interact with async messaging successfully.

Let us start to walk through the contract test on both sides step by step.

Producer Side

1. include `spring-cloud-starter-contract-verifier`
dependency in pom.xml

<dependency>
    <groupId>org.springframework.cloud</groupId>
    <artifactId>spring-cloud-starter-contract-verifier</artifactId>
    <scope>test</scope>
</dependency>

2. include `spring-cloud-contract-maven-plugin`
maven plugin in pom.xml

You also need configure baseClassMappings
to define Base Class for auto-created test class in produer side. You can configure here at first and implement the Base Class in the following step.

<plugin>
    <groupId>org.springframework.cloud</groupId>
    <artifactId>spring-cloud-contract-maven-plugin</artifactId>
    <version>${spring-cloud-contract.version}</version>
    <extensions>true</extensions>
    <configuration>
        <baseClassMappings>
            <baseClassMapping>
                <contractPackageRegex>.*messaging.*</contractPackageRegex>
                <baseClassFQN>.rti.equipmentactivity.MessagingContractBase</baseClassFQN>
            </baseClassMapping>
        </baseClassMappings>
    </configuration>
</plugin>

3. write contract in groovy format

You can create sub folder in $rootDir/src/test/resources/contracts
, and then put the contract file into it.

import org.springframework.cloud.contract.spec.Contract


Contract.make {
    label 'triggerEquipmentInfoSendOutLabel'  //1
    input {
        triggeredBy('triggerEquipmentInfoSendOut()')  //2
    }
    outputMessage {
        sentTo( $(consumer('input'), producer('output')) )  //3
        body([  //4
            equipmentId  : $(producer(regex('[A-Z]{4}[0-9]{6}'))),
            equipmentSize: "20GP",
            events       : [[
                          operation: 'EXPORT',
                          eventId  : $(producer(regex('[A-Z]{4}[0-9]{8}'))),
                          status   : 'OK'
                  ], [
                          operation: 'INPUT_PROCESSING',
                          eventId  : $(producer(regex('[A-Z]{4}[0-9]{8}'))),
                          status   : 'FAILED'
                  ]
            ]
        ])
        headers {
            header('kafka_messageKey', $(producer(regex('[A-Z]{4}[0-9]{6}'))))
            messagingContentType(applicationJson())
        }
    }
}

Notes:

contract label, which can be used to trigger sending event from stub when do test in consummer side.
input trigger for produer side auto-created test codes, baseClassForTests need to implement it.
For producer side, event will be sent to output
channel. For consummer side, event will come from input
channel.
event payload body. Field value can use String or Regex for match.

4. implement `MessagingContractBase`
base class for tests

package com.yyssky.rti.equipmentactivity;


@RunWith(SpringRunner.class)
@SpringBootTest(webEnvironment = SpringBootTest.WebEnvironment.NONE)
@AutoConfigureMessageVerifier
public abstract class MessagingContractBase {


    //@Autowired
    //private MessageVerifier verifier;


    public void triggerEquipmentInfoSendOut() {
    }


}

run mvn clean install
, test will be failed since triggerEquipmentInfoSendOut() do nothing, codes for messaging outgoing is not implemented.

5. implement messaging outgoing codes

You need to add a class and method in it to send out event as below.

@Service
@EnableBinding({Processor.class})
public class EquipmentActivityService {


    @Autowired
    private Processor processor;


    public void sendEquipmentInfo() {


        RtiEvent event1 = RtiEvent.builder().eventId("ASDF12345678").operation("EXPORT").status("OK").build();
        RtiEvent event2 = RtiEvent.builder().eventId("QWER09876543").operation("INPUT_PROCESSING").status("FAILED").build();
        List<RtiEvent> list = new ArrayList<>();
        list.add(event1);
        list.add(event2);
        EquipmentInfo equipmentInfo = EquipmentInfo.builder().equipmentId("ZXCV567890").equipmentSize("20GP").events(list).build();


        Message<EquipmentInfo> message = MessageBuilder
                .withPayload(equipmentInfo)
                .setHeader(KafkaHeaders.MESSAGE_KEY, equipmentInfo.getEquipmentId())
                .build();


        processor.output().send(message);


    }
}

Then you need to call the method in triggerEquipmentInfoSendOut() in the base test class.

package com.yyssky.rti.equipmentactivity;


@RunWith(SpringRunner.class)
@SpringBootTest(webEnvironment = SpringBootTest.WebEnvironment.NONE)
@AutoConfigureMessageVerifier
public abstract class MessagingContractBase {


    @Autowired
    private EquipmentActivityService equipmentActivityService;


    public void triggerEquipmentInfoSendOut() {


        equipmentActivityService.sendEquipmentInfo();
    }


}

run mvn clean install
again and the test should be past. You also can check stub jar is created and installed in local m2 repo.

Now produer side has passed the contract test and also stub jar for consummer side is installed, we can start to do contract test in consummer side now.

Consummer Side

1. include `spring-cloud-starter-contract-stub-runner`
dependency in pom.xml

<dependency>
    <groupId>org.springframework.cloud</groupId>
    <artifactId>spring-cloud-starter-contract-stub-runner</artifactId>
    <scope>test</scope>
</dependency>

2. include Messaging Producer's stub dependency in pom.xml

<dependency>
    <groupId>com.yyssky.rti</groupId>
    <artifactId>equipment-activity</artifactId>
    <classifier>stubs</classifier>
    <version>0.0.1-SNAPSHOT</version>
    <scope>test</scope>
    <exclusions>
        <exclusion>
            <groupId>*</groupId>
            <artifactId>*</artifactId>
        </exclusion>
    </exclusions>
</dependency>

3. write contract test class

@RunWith(SpringRunner.class)
@SpringBootTest(webEnvironment = SpringBootTest.WebEnvironment.NONE)
@AutoConfigureStubRunner(stubsMode = StubRunnerProperties.StubsMode.LOCAL, ids = "com.yyssky.rti:equipment-activity")
public class EquipmentCmdListenerTests {


    @Autowired
    private StubTrigger stubTrigger;


    @Autowired
    private EquipmentCmdListener equipmentCmdListener;


    @Test
    public void shouldReceiveEquipmentInfo() {


        Assertions.assertThat(equipmentCmdListener.getReceivedEvents()).hasSize(0);
        stubTrigger.trigger("triggerEquipmentInfoSendOutLabel");


        Assertions.assertThat(equipmentCmdListener.getReceivedEvents()).hasSize(1);




    }
}

In the test method, we use StubTrigger
to trigger stub send out event about the contract label.

run mvn clean test
it will be fail, since we have not implemented event listener in EquipmentCmdListener class. Let us do it.

4. implement `EquipmentCmdListener`
class to pass the test

@Component
@EnableBinding({Processor.class})
@Slf4j
public class EquipmentCmdListener {


    private List<EquipmentInfo> receivedEvents = new ArrayList<>();


    @StreamListener(Processor.INPUT)
    public void onEvent(@Payload EquipmentInfo equipmentInfo){
        log.info("************* receive event, equipmentInfo: {}", equipmentInfo.toString());


        receivedEvents.add(equipmentInfo);  //just for test
    }


    public List<EquipmentInfo> getReceivedEvents() {
        return receivedEvents;
    }




}

In the EquipmentCmdListener class, the List is just for test.

run mvn clean test
again, consummer side contract test will be pass.

END
