@10 ➜ ~  docker version
Client: Docker Engine - Community
 Version:           20.10.7
 API version:       1.41
 Go version:        go1.13.15
 Git commit:        f0df350
 Built:             Wed Jun  2 11:58:10 2021
 OS/Arch:           linux/amd64
 Context:           default
 Experimental:      true


Server: Docker Engine - Community
 Engine:
  Version:          20.10.7
  API version:      1.41 (minimum version 1.12)
  Go version:       go1.13.15
  Git commit:       b0f5bc3
  Built:            Wed Jun  2 11:56:35 2021
  OS/Arch:          linux/amd64
  Experimental:     false
 containerd:
  Version:          1.4.6
  GitCommit:        d71fcd7d8303cbf684402823e425e9dd2e99285d
 runc:
  Version:          1.0.0-rc95
  GitCommit:        b9ee9c6314599f1b4a7f497e1f1f856fe433d3b7
 docker-init:
  Version:          0.19.0
  GitCommit:        de40ad0

[mysqld]
server-id=1
log-bin=master-bin
log-bin-index=master-bin.index

docker run -p 3306:3306 --name mysql_master \
--privileged=true \
-v /home/dev/data/mysql/conf:/etc/mysql/conf.d \
-v /home/dev/data/mysql/logs:/logs \
-v /home/dev/data/mysql/data:/var/lib/mysql \
-e MYSQL_ROOT_PASSWORD=master123 -d mysql:5.7

# 进入容器内部
docker exec -it mysql_master /bin/bash


# 使用mysql命令行工具
mysql -uroot -pmaster123


# 创建用户并分配权限
mysql> CREATE USER 'slave'@'%' IDENTIFIED BY 'slave'; #创建用户
mysql> GRANT REPLICATION SLAVE ON *.* TO 'slave'@'%'; #分配权限
mysql> flush privileges;   #刷新权限

mysql> show master status;
+-------------------+----------+--------------+------------------+-------------------+
| File              | Position | Binlog_Do_DB | Binlog_Ignore_DB | Executed_Gtid_Set |
+-------------------+----------+--------------+------------------+-------------------+
| master-bin.000003 |      749 |              |                  |                   |
+-------------------+----------+--------------+------------------+-------------------+
1 row in set (0.01 sec)

[mysqld]
server-id=2
relay-log-index=slave-relay-bin.index
relay-log=slave-relay-bin

docker run -p 3306:3306 --name mysql_slave01  \
--privileged=true \
-v /home/dev/data/mysql/conf:/etc/mysql/conf.d \
-v /home/dev/data/mysql/logs:/logs \
-v /home/dev/data/mysql/data:/var/lib/mysql  \
-e MYSQL_ROOT_PASSWORD=slave123 \
-d mysql:5.7


docker run -p 3306:3306 --name mysql_slave02  \
--privileged=true \
-v /home/dev/data/mysql/conf:/etc/mysql/conf.d \
-v /home/dev/data/mysql/logs:/logs \
-v /home/dev/data/mysqldata:/var/lib/mysql  \
-e MYSQL_ROOT_PASSWORD=slave123 \
-d mysql:5.7


# --privileged=true ：指定当前容器具有宿主机的root权限

# 进入容器内部
docker exec -it mysql_slave01 /bin/bash


# 使用mysql命令行工具
mysql -uroot -pslave123


# 配置主库信息
mysql> change master to master_host='192.168.33.51', master_port=3306, master_user='slave', master_password='slave', master_log_file='master-bin.000003', master_log_pos=749, master_connect_retry=30;
Query OK, 0 rows affected, 2 warnings (0.02 sec)


# 开启复制
mysql> start slave;
Query OK, 0 rows affected (0.00 sec)


# 查看从库状态
mysql> show slave status\G;
*************************** 1. row ***************************
               Slave_IO_State: Waiting for master to send event
                  Master_Host: 192.168.33.10
                  Master_User: slave
                  Master_Port: 3307
                Connect_Retry: 30
              Master_Log_File: master-bin.000003
          Read_Master_Log_Pos: 749
               Relay_Log_File: slave-relay-bin.000002
                Relay_Log_Pos: 321
        Relay_Master_Log_File: master-bin.000003
             Slave_IO_Running: Yes
            Slave_SQL_Running: Yes
              Replicate_Do_DB:
          Replicate_Ignore_DB:
           Replicate_Do_Table:
       Replicate_Ignore_Table:
      Replicate_Wild_Do_Table:
  Replicate_Wild_Ignore_Table:
                   Last_Errno: 0
                   Last_Error:
                 Skip_Counter: 0
          Exec_Master_Log_Pos: 749
              Relay_Log_Space: 528
              Until_Condition: None
               Until_Log_File:
                Until_Log_Pos: 0
           Master_SSL_Allowed: No
           Master_SSL_CA_File:
           Master_SSL_CA_Path:
              Master_SSL_Cert:
            Master_SSL_Cipher:
               Master_SSL_Key:
        Seconds_Behind_Master: 0
Master_SSL_Verify_Server_Cert: No
                Last_IO_Errno: 0
                Last_IO_Error:
               Last_SQL_Errno: 0
               Last_SQL_Error:
  Replicate_Ignore_Server_Ids:
             Master_Server_Id: 1
                  Master_UUID: ea044309-df3d-11eb-8a4b-0242ac110004
             Master_Info_File: /var/lib/mysql/master.info
                    SQL_Delay: 0
          SQL_Remaining_Delay: NULL
      Slave_SQL_Running_State: Slave has read all relay log; waiting for more updates
           Master_Retry_Count: 86400
                  Master_Bind:
      Last_IO_Error_Timestamp:
     Last_SQL_Error_Timestamp:
               Master_SSL_Crl:
           Master_SSL_Crlpath:
           Retrieved_Gtid_Set:
            Executed_Gtid_Set:
                Auto_Position: 0
         Replicate_Rewrite_DB:
                 Channel_Name:
           Master_TLS_Version:
1 row in set (0.00 sec)


ERROR:
No query specified


# 看到以下两个状态为Yes表示复制正常进行
    # Slave_IO_Running: Yes
    # Slave_SQL_Running: Yes
