Temporal-Frequency Masked Autoencoders for

Time Series Anomaly Detection

Yuchen Fang

, Jiandong Xie

, Yan Zhao

3,∗

, Lu Chen

, Yunjun Gao

, Kai Zheng

1,∗

University of Electronic Science and Technology of China, China

Huawei Cloud Database Innovation Lab, China

Aalborg University, Denmark

Zhejiang University, China

fyclmiss@gmail.com, xiejiandong@huawei.com, yanz@cs.aau.dk, {luchen,gaoyj}@zju.edu.cn, zhengkai@uestc.edu.cn

Abstract—In the era of observability, massive amounts of time

series data have been collected to monitor the running status

of the target system, where anomaly detection serves to identify

observations that differ signiﬁcantly from the remaining ones and

is of utmost importance to enable value extraction from such

data. While existing reconstruction-based methods have demon-

strated favorable detection capabilities in the absence of labeled

data, they still encounter issues of training bias on abnormal

times and distribution shifts within time series. To address these

issues, we propose a simple yet effective Temporal-Frequency

Masked AutoEncoder (TFMAE) to detect anomalies in time series

through a contrastive criterion. Speciﬁcally, TFMAE uses two

Transformer-based autoencoders that respectively incorporate

a window-based temporal masking strategy and an amplitude-

based frequency masking strategy to learn knowledge without

abnormal bias and reconstruct anomalies by the extracted normal

information. Moreover, the dual autoencoder undergoes training

through a contrastive objective function, which minimizes the

discrepancy of representations from temporal-frequency masked

autoencoders to highlight anomalies, as it helps alleviate the

negative impact of distribution shifts. Finally, to prevent over-

ﬁtting, TFMAE adopts adversarial training during the training

phase. Extensive experiments conducted on seven datasets pro-

vide evidence that our model is able to surpass the state-of-the-art

in terms of anomaly detection accuracy.

Index Terms—time series anomaly detection, temporal-

frequency analysis, masked autoencoder

I. INTRODUCTION

Time series is a sequence of temporally ordered observa-

tions, and the analysis of it has swiftly become a focal task

in academic and industrial research, propelled by advances in

our capability of time series data collection and storage in the

context of sensor networks, cloud computing, and especially

the recent emerging concept of observability [1], [2]. Anomaly

detection is an indispensable task in time series analysis,

determining whether the data conforms to the normal data dis-

tribution, and the non-conforming parts are called anomalies.

Timely alerts for anomalies can empower system maintainers

to proactively conduct maintenance, enabling sustainability

and safety in real applications such as fraud detection [3],

intrusion detection [4], and energy management [5].

∗

Corresponding author: Kai Zheng and Yan Zhao. Kai Zheng is with

Shenzhen Institute for Advanced Study, University of Electronic Science and

Technology of China, Shenzhen, China

However, providing accurate time series anomaly detection

is a non-trivial task because patterns of time series are intricate

and dynamic in various applications, which makes it hard

to seek a general manner for deﬁning anomalies accurately.

Moreover, with the scarcity of labeled data, the progress of

supervised methods for time series anomaly detection is im-

peded. Unsupervised approaches can detect anomalies without

labeled data, which often relies on density-based methods

(leveraging discrepancies between neighbors) and clustering-

based methods (utilizing distances from cluster centers). As the

time series data scale grows larger and deep learning excels

in data analysis, recent endeavors turn to reconstructing time

series with intricate temporal correlations and multivariate

dependencies by using various deep learning models. These

models focus on the discrepancy between the reconstructed

and original time series. Innovations like OmniAno [6], Times-

Net [7], and TranAD [8] introduce the recurrent neural net-

work, convolution neural network, and Transformer network

into the time series anomaly detection, respectively.

Despite recent improvements, existing deep reconstruction-

based methods still face the following challenges.

Challenge I: Abnormal bias. Deep learning models heavily

rely on the learned knowledge from data during the training

phase, yet extracting information from time series proves more

challenging than language and image data due to its intricate

patterns [9], [10]. Therefore, learning a high-quality recon-

struction model becomes particularly hard, especially in the

presence of knowledge-agnostic abnormal bias. As depicted

in the left of Figure 1, TimesNet [7], a typical reconstruction

model, is able to well reconstruct normal series, yet overﬁts

abnormal observations, leading to performance degradation.

This phenomenon arises from the incorporation of misleading

abnormal bias, which can blend into normal patterns through

the commonly used temporal modeling. Unfortunately, many

existing reconstruction-based methods overlook this abnormal

bias, resulting in suboptimal performance.

Challenge II: Time series distribution shift. The distribu-

tion shift of time series introduces a crucial factor, wherein

patterns learned from training data may become unsuitable

or even incorrect for testing data, which results in erroneous

reconstructed time series. As shown in the right of Figure 1,

the curve of the cumulative score on the testing data goes up

1228

2024 IEEE 40th International Conference on Data Engineering (ICDE)

DOI 10.1109/ICDE60146.2024.00099

Authorized licensed use limited to: Huawei Technologies Co Ltd. Downloaded on August 23,2024 at 09:42:52 UTC from IEEE Xplore. Restrictions apply.

0 20 40 60 80 100

Time

-4

-2

Value

Input

Reconstructed

Score

0.0 0.2 0.4 0.6 0.8 1.0

Anomaly Score

0.0

0.2

0.4

0.6

0.8

1.0

Density

Test

Val

Threshold

Fig. 1: Left: TimesNet [7] conducts anomaly detection on the

synthetic NIPS-TS-Global dataset. Right: Cumulative distribu-

tion function (CDF) of the anomaly scores on the real-world

SMAP validation and test sets for TimesNet.

faster than those on the validation data, which is attributed

to the distribution shift of time series and contributes to

poor generalization on the threshold. Despite there are two

types of existing techniques that can be incorporated into

reconstruction-based methods to mitigate distribution shifts:

normalization and decomposition. The static statistics-based

normalization [11], [12] and pre-deﬁned parameters-based

decomposition [9], [13]–[15] exhibit limitations in general-

ization. Moreover, methods relying on learned statistics [16]

and parameters [17], [18] remain susceptible to the inﬂuence

of distribution shifts.

This work aims to address the above challenges by design-

ing a pioneering model, called Temporal-Frequency Masked

AutoEncoder (TFMAE), which is trained through an ad-

versarial contrastive objective function. For abnormal bias,

recognizing the importance of purifying time series, we imple-

ment a window-based temporal masking strategy to eliminate

potential observation anomalies (e.g., global and contextual

observation anomalies) with a large coefﬁcient of variation,

and an amplitude-based frequency masking strategy to elim-

inate potential pattern anomalies (e.g., trend and seasonal

anomalies) with a small amplitude. These strategies are ben-

eﬁcial for learning without abnormal bias and reconstructing

anomalies with the learned normal knowledge. To tackle the

distribution shift issue, we initially devise two Transformer-

based autoencoders to generate distinct representations of our

temporal and frequency masking-based time series. Then a

novel contrastive objective function is introduced to minimize

the discrepancy between these representations. Finally, the

contrastive discrepancy replaces the conventional reconstruc-

tion error for anomaly detection, as the discrepancy between

anomalies and their corresponding normal-recovered views

exceeds that of normal representations. Breaking free from

the reconstruction paradigm, the contrastive criterion leverages

the fact that the similarity of different views is distribution-

agnostic [19]. Besides, to avoid over-ﬁtting in minimizing dis-

crepancy, adversarial training is integrated into our TFMAE.

Our contributions can be summarized as follows:

• To eliminate potential abnormal observations and patterns

before modeling, we present a window-based tempo-

ral masking strategy and an amplitude-based frequency

masking strategy. Therefore, autoencoders with puriﬁed

inputs are not misled by observation and pattern anoma-

lies, i.e., TFMAE is an abnormal bias-resistant model.

• To the best of our knowledge, this work is the ﬁrst study

that replaces the reconstruction error with the temporal

and frequency masking-based contrastive criterion for

time series anomaly detection, which is a distribution shift

unaffected model.

• We conduct extensive experiments on seven public real

time series datasets, and the results offer insight into the

effectiveness and efﬁciency of TFMAE.

Section II surveys the related work. The problem statement

and the system overview are introduced in Section III. We then

present TFMAE in Section IV, followed by the experimental

results in Section V. Section VI concludes this paper.

II. R

ELATED WORK

A. Time Series Anomaly Detection

Numerous studies have been conducted on time series

anomaly detection. Based on the manners of detecting anoma-

lies, we can divide the methods into ﬁve types: density-based

methods, clustering-based methods, label-based methods, re-

construction-based methods, and contrastive-based methods.

Density-based methods mainly focus on the discrepancy

between observations and their neighbors. The density-based

local outlier factor (LOF) [20] and connectivity-based con-

nectivity outlier factor (COF) [21] are two typical traditional

density-based methods. As deep representational learning

gained traction, advanced models such as DAGMM [22] and

MPPCACD [23] learn low-dimensional representations of time

series and utilize the Gaussian Mixture Model to derive their

density, which achieves highly accurate detection results.

Clustering-based methods leverage distances between ob-

servations and the cluster center to discern anomalies. Tak-

ing clustering into consideration, classic techniques such as

support vector data description (SVDD) [24] and one-class

support vector machine (OC-SVM) [25] search the hyper-

sphere and hyperplane in the kernel space. Subsequently,

DSVDD [26] and THOC [27] are proposed to seek clusters in

the deep latent and hierarchical space for anomaly detection.

Label-based methods engage in supervised classiﬁcation

during the training phase. Microsoft [28] pioneered the use of

human-generated labels to train a CNN model for anomaly de-

tection. Extending this approach, RobustTAD [29] introduces

the assignment of label and value weights to labels and crucial

points to improve detection performance.

Reconstruction-based methods have been a cornerstone of

research, particularly in the absence of labeled training data.

These models are trained in an unsupervised manner, detecting

anomalies by discerning discrepancies between original and

reconstructed time series. In the earlier years, reconstruc-

tion relied on statistical methods like ARIMA [30]. The

advent of deep learning gave rise to methods such as Omni-

Ano [6], HIFI [31], Interfusion [32], TFAD [13], VQRAE [33],

RDAE [34], and TimesNet [7]. They reconstruct time series

1229

Authorized licensed use limited to: Huawei Technologies Co Ltd. Downloaded on August 23,2024 at 09:42:52 UTC from IEEE Xplore. Restrictions apply.

of 14

免费下载

关注

评论
