SecCT: Secure and scalable count query models on

encrypted genomic data

Yanguo Peng, Rongqiao Liu, Xiyue Gao, Luyuan Huang

School of Computer Science and Technology

Xidian University

Xi’an, China

Jingjing Guo

School of Cyber Engineering

Xidian University

Xi’an, China

Yaofeng Tu

ZTE Corporation

Nanjing, China

Abstract—Recently, due to the continued reduction in DNA

sequencing cost, large-scale genetic samples are being gathered

for accelerating predispositions to speciﬁc diseases, tailoring

treatment of efﬁcient drugs and therapies, etc. Massive genetic

samples are encrypted-and-then-delegated to a public cloud

to both save investment and maintenance costs and prevent

the potential leakage of sensitive information. However, such a

manner compromises the serviceability of a public cloud, since

encryption inevitably breaks the semantic information of genetic

samples. Secure count query of single-nucleotide polymorphisms

(SNPs), as a kernel component for GWASs and related genomic

analysis, is attracting much more attention.

Existing methods lack provable security, suffer low efﬁciency

caused by multiple interactions with the cloud, etc. In this

paper, a secure virtual CT-Tree (secure vCT-Tree) is carefully

constructed to confuse the tree structure by introducing a hash

function and a Paillier system. Furthermore, by delegating the

secure vCT-Tree to the cloud, concrete models (i.e., SecCT and

SecCT+) are presented to resolve secure count query problems

on-the-ﬂy. Both models advance the provable security of genetic

research and are proven to be secure under the adaptive cho-

sen keyword (query) attack (IND-CKA2) model. Furthermore,

massive experiments are evaluated on realistic data to show the

superiority of SecCT.

Index Terms—Secure count query, genotypic and phenotypic

data, IND-CKA security, scalability

I. INTRODUCTION

DNA sequencing costs have dramatically decreased in re-

cent years. The acquisition of large-scale genetic samples has

become feasible and ubiquitous. Genetic samples are widely

applied in various biomedical research and industry ﬁelds.

For example, these genetic samples provide predispositions

to speciﬁc diseases (such as hypertension [2], Alzheimer [3],

etc.), tailor treatment with personalized medicine [5] and the

development of efﬁcient drugs and therapies. For promoting

the above related research many countries and organizations

around the world have started collecting these genetic data,

such as UK Biobank [6], The 1000 Genomes Project

, etc.

Both the volume and scale of genetic samples are enormous

since a human’s DNA sequence consists of almost 3.16 billion

The work is supported by the National Natural Science Foundation of China

(No. 62172314, 62302370, 61602360), the Natural Science Basic Research

Program of Shaanxi Province (No.2023-JC-QN-0648, 2019CGXNG-023) and

ZTE Industry-University-Institute Cooperation Funds (No. IA20230625001).

J. Guo is the corresponding author.

https://www.internationalgenome.org/

of base pairs

and there are around 350 million people

on earth living with rare disorders in which 80% of these

are genetic-related

. It is rarely possible for organizations

and companies to leverage genetic samples locally. Cloud

computing is a solution that is gaining traction in genomics

research [7]. Funders of genomics research are willing to

utilize cloud computing’s advantages and move their various

genomic resources to the cloud accordingly.

The human genome is a special information carrier, which

indicates a plethora of human’s essential and private charac-

teristics. Once an individual’s genome is leaked there will be

no feasible measure to protect it any longer. Additionally, the

genome reﬂects an individual’s character [8], identiﬁes predis-

position to diseases [1]–[3], etc. Thus, a human’s genome is

prone to privacy risks and attacks. So far, security and privacy

remain the main obstacle for biomedical organizations and

companies to fully embrace cloud computing.

The encrypt-then-outsource model is widely adopted to

prevent the leakage of private information on clouds. In such

a way, the cloud can learn nothing meaningful about both

the genetic samples and queries without secret keys [9],

[10]. Related works provide different services directly on the

encrypted data, among which genome-wide association studies

(GWASs) have revolutionized the ﬁeld of complex disease

genetics over past decades [11]. Secure count query of single-

nucleotide polymorphisms (SNPs) on large genomic data is

a kernel component for GWASs and related genomic analysis

(e.g., paternity and disease susceptibility tests). For example, a

count query is used to derive statistical results of rare variants

(e.g., SNP) and a GWAS system utilizes the result to build

associations between gene and disease [7], [12], [13].

Several solutions have been proposed in previous works [13]

to resolve the problem of secure count queries on genomic

data. Various solutions [14]–[17] are proposed to resolve the

problem by levering cryptographic algorithms and hardware.

These solutions suffer limitations of low efﬁciency, multi-

round interactions, secure hardware investment, etc., and hence

are difﬁcult to be deployed in practice. Also, they are not

compatible with phenotypic data, which is as important as

genomic data in GWASs and related genomic analysis. Hansan

https://en.wikipedia.org/wiki/Base_pair

https://www.genome.gov/dna-day/15-ways/rare-genetic-diseases

2023 IEEE 28th Pacific Rim International Symposium on Dependable Computing (PRDC)

DOI 10.1109/PRDC59308.2023.00011

Authorized licensed use limited to: ZTE Corporation (One Dept). Downloaded on June 08,2025 at 03:29:13 UTC from IEEE Xplore. Restrictions apply.

et al. [18] proposed the ﬁrst solution on both genotypic

and phenotypic data by levering a tree structure. However,

multiple rounds of interaction in such a solution still restrict

the performance of secure count queries since the tree structure

can only be recursively accessed. Most importantly, none of

the above schemes provide formal security proofs which is far

from practical security.

In this paper, based on a rigorous security model secure

count query models on encrypted genomic data are presented

to support GWASs and related genomic analysis on-the-ﬂy.

The main contributions are as follows.

• Scalable and efﬁcient storage of genomic data. For a

genomic dataset consisting of both genotypic and phe-

notypic data, a counting tree (CT-Tree) is designed for

storing both the genomic data and count values by

embedding both genotypic and phenotypic data into edges

between nodes in the tree.

• Secure organization on clouds. Furthermore, all nodes in

CT-Tree are encrypted and make up a secure virtual CT-

Tree (secure vCT-Tree) by levering a hash function and an

efﬁcient homomorphic encryption. The secure vCT-Tree

prevents the leakage of both tree structures and contents

in all nodes and leaves.

• Secure and efﬁcient count query. Based on delegating a

secure vCT-Tree to a semi-honest cloud, two secure count

query models (i.e., SecCT and SecCT+) are presented in

which there is only a single interaction with the cloud.

• Provable security and high efﬁciency. SecCT is theoreti-

cally proven to be secure under indistinguishability under

adaptive chosen keyword (query) attack (IND-CKA2)

model. Also, massive experimental evaluations have been

conducted on real datasets to support the superiority of

SecCT and SecCT+.

So far, SecCT and SecCT+ are the ﬁrst secure count query

models that are proven to be secure under the IND-CKA2

model and that need only a single interaction with a cloud.

The rest of this paper is organized as follows. We review

the related works and present brief comparisons with SecCT in

section II. The formal problem deﬁnition, security model, and

related fundamental tools are stated in section III. The genomic

data organization on the cloud is discussed in section IV, based

on which the concrete SecCT is presented in section V. In

section VI, SecCT is theoretically analyzed, such as security

analysis, theoretical efﬁciency, and theoretical comparison. We

present experimental evaluation in section VII and conclude

this work in section VIII.

II. R

ELATED WORK

Solutions towards ensuring the privacy and security of

genomic data while preserving functionalities are already a

research hotspot in biomedical and security communities [12],

[13]. There has been some progress in the secure count query.

Kantarcioglu et al. [14] ﬁrst presented a concrete secure count

query scheme in 2008. Since then, the secure count query

problem has been investigated in various works [15], [17],

[18]. In the following, we brieﬂy review these works from

various aspects and summarize them in Table I.

First, for security, data privacy, as the fundamental require-

ment, is satisﬁed since genomic data is prevented from leakage

in all the above works. Output privacy preventing the leakage

of a count query’s result is achieved in works [15], [17], [18].

Query privacy, satisfying that there is no adversary that can

learn anything about the query, is only considered in [17], [18].

All the analyses are descriptively driven under non-standard

security models. The capabilities of the attacker are not deﬁned

by an adversarial model. So far, there is little progress in the

provable secure count query. SecCT and SecCT+ are the ﬁrst

attempts toward the provable security of count query.

From an architectural perspective, works in references [14],

[17] both introduce multiple clouds to collaborate on secure

count query tasks. Such solutions are constructed on a con-

sistent assumption that multiple clouds do not compromise

with each other and one of the clouds is trusted, which is a

nature drawback compared with single cloud architecture. In

reference [15] the proposal works on a secure cryptographic

co-processor (SCP). It suffers the memory limitation of SCP

itself and is not compatible with large-scale genomic data.

Hasan et al. [18] proposed the ﬁrst scheme utilizing a single

cloud. But multiple interactions between a client and a cloud

are inevitable to resolve secure count queries. SecCT and

SecCT+ are the ﬁrst secure count query models utilizing

a single cloud and circumventing multiple interactions to

accelerate the query.

Hasan et al. [18] presented the ﬁrst secure count query work-

ing on both genotypic and phenotypic data. Other works [14],

[15], [17] are only for genotypic data. SecCT and SecCT+

are also compatible with both genotypic and phenotypic data.

Additionally, all the above schemes except SecCT and SecCT+

cannot support dataset updating directly on the cloud.

III. P

RELIMINARIES

In this section, we present a framework to resolve the secure

count query problem on both genotypic and phenotypic data.

Following that security model is carefully designed to lay a

solid foundation for security. In the end, the Paillier system is

introduced.

As shown in Fig. 1, there are three participants in the

secure framework for secure count query on both genotypic

and phenotypic data.

• A data owner dominates a genomic dataset. A secure

index is constructed by embedding the genomic dataset.

Then, the secure index is delegated to a public cloud for

providing clients service of secure count query. A data

owner in practice is a hospital, health center, biobank, or

other similar institution that collects genomic data.

• A cloud stores the delegated secure index. When re-

ceiving a legal request for a count query from a client,

it conducts the query directly on the secure index and

derives the encrypted result. A cloud in practice is a cloud

service provider, such as AWS, Google Cloud, etc.

Authorized licensed use limited to: ZTE Corporation (One Dept). Downloaded on June 08,2025 at 03:29:13 UTC from IEEE Xplore. Restrictions apply.

of 10

免费下载

goldendb paper

关注

评论
