International Journal of Automation and Computing

DOI: 10.1007/s11633-018-1126-y

A Survey of Scene Understanding by Event Reasoning in

Autonomous Driving

Jian-Ru Xue

Jian-Wu Fang

1,2

Pu Zhang

Institute of Artiﬁcial Intelligence and Robotics, Xi



an Jiaotong University, Xi



an, 710049, China

Chang



an University, Xi



an, 710064, China

Abstract: Realizing autonomy is a hot research topic for automatic vehicles in recent years. For a long time, most of the eﬀorts

to this goal concentrate on understanding the scenes surrounding the ego-vehicle (autonomous vehicle itself). By completing low-

level vision tasks, such as detection, tracking and segmentation of the surrounding traﬃc participants, e.g., pedestrian, cyclists and

vehicles, the scenes can be interpreted. However, for an autonomous vehicle, low-level vision tasks are largely insuﬃcient to give help

to comprehensive scene understanding. What are and how about the past, the on-going and the future of the scene participants? This

deep question actually steers the vehicles towards truly full automation, just like human beings. Based on this thoughtfulness, this

paper attempts to investigate the interpretation of traﬃc scene in autonomous driving from an event reasoning view. To reach this

goal, we study the most relevant literatures and the state-of-the-arts on scene representation, event detection and intention prediction

in autonomous driving. In addition, we also discuss the open challenges and problems in this ﬁeld and endeavor to provide possible

solutions.

Keywords: Autonomous vehicle, scene understanding, event reasoning, intention prediction, scene representation.

1 Introduction

• Automation is one of the hottest topics in transp orta-

tion research and could yield completely driverless cars

in less than a decade. — Nature in 2015

[1]

Can the driverless cars be completely yielded in less than

a decade? Manifestly, it is still decades away based on the

observations of current progresses and remaining challenges

in autonomous vehicles. So far, no one is close to develop

a fully autonomous vehicle. The ﬂeet testing by Uber and

Google operates under tightly controlled conditions

[2]

The reasons are from four aspects: 1) The exist-

ing methods of environment perception, e.g., detection

[3]

tracking

[4, 5]

and segmentation

[6]

of participants in traf-

ﬁc scenes, still produce inevitable errors in real environ-

ment; 2) The driving environment is rather complex, unpre-

dictable, dynamic, and uncertain; 3) Deep traﬃc scene un-

derstanding, such as understanding the geometry/topology

structure of scene, and spatio-temporal evolution of partic-

ipants (pedestrian, vehicle, etc.), is studied far from suﬃ-

cient, whose ultimate goal is to semantically reasoning the

scene evolvement so as to provide clues for behavior deci-

sion and autonomous vehicle control. Actually, it is dif-

Review

Manuscript received October 16, 2017; accepted March 9, 2018

This work was supported by National Key R&D Program Project of

China (No. 2016YFB1001004), Natural Science Foundation of China

(Nos. 61751308, 61603057, 61773311), China Postdoctoral Science

Foundation (No. 2017M613152), and Collaborative Research with

MSRA.

Recommended by Associate Editor Matjaz Gams

 Institute of Automation, Chinese Academy of Sciences and

Springer-Verlag Gmbh Germany, part of Springer Nature 2018

ﬁcult to study because these elements are implicitly con-

tained in the driving environment and cannot be directly

observed; 4) The deployment of autonomous vehicle faces

social dilemma and involves moral issue

[7]

. Complementary

to our survey, Janai et al.

[8]

exhaustively reviewed the traf-

ﬁc participant recognition, detection and tracking, scene

reconstruction, motion estimation, semantic segmentation,

and many other vision-based tasks. Xue et al.

[9]

made an

overview on autonomous vehicle systems from the perspec-

tives of self-localization and multi-sensor fusion for obstacle

detection and tracking, and emphasized vision-centered fu-

sion of multiple sensors. Zhu et al.

[10]

studied the latest

progresses on lane detection, traﬃc sign/light recognition

in the perception of intelligent vehicles. These surveys, to

a great extent, give a comprehensive and detailed investi-

gation concerning with the ﬁrst reason mentioned above.

In this paper, we focus on the third aspect: survey on the

deep understanding of traﬃc scene for autonomous vehicles.

This paper aims to explore the evolution of traﬃc scene

from an event reasoning view. That is because event can

reﬂect the dynamic evolution process of scene with tractable

reasoning strategy

[11]

. In order to provide a clear and logi-

cal investigation, this paper reasons the event from its rep-

resentation, detection, as well as prediction stages. In the

representation stage, the main goal is to obtain high-level

clues for the following stages. In this stage, we expound

the saliency, the contextual layout, and the topology rules

for autonomous driving. As for the detection stage, we

review the event detection with respect to diﬀerent partic-

ipants, such as pedestrian and vehicles. For the prediction

stage, this paper elaborates the intention of autonomous

2 International Journal of Automation and Computing

vehicles with regard to the expected time span for future

prediction. We classify the prediction of intention as long-

term intention prediction and short-term prediction. Fig. 1

demonstrates the surveying ﬂowchart in this paper. At dis-

tinct stages, we discuss open problems and challenges, and

endeavour to provide possible solutions.

Fig. 1 The scene understanding ﬂowchart by event reasoning

framework for autonomous driving

Actually, beyond those stages, some end-to-end ap-

proaches emerge recently for scene understanding facing

autonomous driving

[12−14]

. They rely on a large-scale data-

driven mechanism, and formulate the scene to decide with

deep layers or recursive perception, such as fast recurrent

fully convolutional networks (FCN) for direct perception in

autonomous driving

[12]

and FCN-LSTM

[13]

for a future mo-

tion action feasibility distribution. We specially take a sec-

tion to present this category. We hope that our survey can

sweep away some entry barriers of deep scene understanding

for autonomous driving, and draw forth meaningful insights

and solutions for this ﬁeld.

1.1 Autonomy pursuit in driving

Developing autonomous systems aim to assist humans

in handing everyday tasks. Autonomous driving system, a

system for closely related to humans



everyday trips, has

become people



s one of the most typical pursuits. It can

free hands from the steering wheel, and spare time for tack-

ling many other things. Meanwhile, the equipped sensors of

autonomous vehicle can also recognize the surrounding con-

dition immediately and ensure safe driving, thus decreasing

traﬃc accidents. Encouraged by those merits, researchers

are diligently pursuing autonomous driving all the time.

There are two kinds of driving force in the development

of autonomous driving. One is the projects launched and

challenges posed by diﬀerent governments, research insti-

tutes and vehicle manufacturers. The other we want to

emphasize is the publicly available benchmarks.

Projects and launched challenges. Since 1986, Eu-

rope started an intelligent transportation system project,

named as PROMETHEUS, involving more than 13 ve-

hicle manufacturers and research institutions around 19

countries. Thorpe et al.

[15]

in Carnegie Mellon University

launched the ﬁrst autonomous driving project in the United

States. This project made breakthrough in 1995 that au-

tonomously drove a car from Pittsburgh, Pennsylvania to

San Diego, California. Supported by many related stud-

ies, the US government established the National Automated

Highway System Consortium (NAHSC) in 1995. Motivated

by these projects, highway scenarios has been intensively

studied for a long time, while urban scene remained as an

uncultivated area. Actually, urban scene is closely related

to human



s daily lives. At that time, a famous “DARPA

Grand Challenge (DUC)” launched by Defense Advanced

Research Projects Agency (DARPA) largely accelerated

the progress of autonomous vehicle. Among them, “Ur-

ban Challenge”

[16]

, the third challenge launched by DARPA

(others had been held in 2004 and 2005 respectively, aiming

to test the self-driving performance in the Mojave Desert of

the United States

[17, 18]

, took place on November 3, 2007 at

the now-closed George Air Force Base in Victorville, Cali-

fornia. Rules included obeying all traﬃc regulations while

negotiating with other vehicles and obstacles and merg-

ing into traﬃc. There were 4 teams completed the route

within 6 hours. In 2009, National Natural Science Foun-

dation of China launched the China Intelligent Vehicle Fu-

ture Challenge (iVFC). Up to now, the ninth contest was

held in November 2017. Google started their self-driving

car project in 2009, and completed over 5 million miles

driving test until March 2018

. In 2016, the project was

evolved into an independent self-driving technology com-

pany Waymo. Tesla Autopilot

, by equipping cameras,

twelve ultrasonic sensors and a forward-facing radar, all the

vehicles can have the self-driving ability since October 2016.

As a matter of fact, more and more vehicle manufacturers,

such as Audi, BMW, Benz, have begin their projects to

develop their self-driving vehicles.

Benchmarks. In 2012, Geiger et al.

[19]

introduced the

KITTI vision benchmark, which contained six diﬀerent ur-

ban scenes, and had 156 video sequences with time span

from 2 minutes to 8 minutes. Within this benchmark,

they launched several typical vision tasks, such as pedes-

trian/vehicle detection, optical ﬂow, stereo ﬂow, road detec-

tion, lane detection, etc. The benchmark was collected by

an ego-vehicle equipped with color and gray cameras, and

Velodyne 3D laser scanner and high-precision GPS/IMU

inertial navigation systems. At the same time, Cambridge

University released CamVid dataset

[20]

, which provided a

semantic segmentation evaluation benchmark containing

only four video sequences on urban scene. Another pop-

ular benchmark is the Cityscapes dataset

[21]

released in

2016. Urban scene was collected in 50 cities, and have 5 000

ﬁne-annotated images and 20 000 coarse-annotated images.

Cityscapes has become the most challenging dataset for

semantic segmentation task. Actually, annotation is time

and labor consuming. Based on that, Gaidon et al.

[22]

con-

structed a large-scale KITTI-like virtual dataset

by com-

puter graphic technology. The beneﬁt of virtual dataset

is that it can generate every wanted task, for those that

https://www.theverge.com/2018/2/28/17058030/waymo-self-

driving-car-360-degree-video

https://www.tesla.com/autopilot

http://www.europe.nav erlabs.com/Research/Computer-

Vision/Proxy-Virtual-Worlds
