step by step install oracle 10g rac asm for windows
5墨值下载
step by step install oracle 10gR2 rac
+ASM on windows using vmware
操作系统 : windows 2003 server 企业版
安装软件包:10G 集群软件包 10201_clusterware_win32.zip 数据库软件包
10201_database_win32.zip
1.安装第一个节点 windows 2003 虚拟机 .....................................................................................1
2.编辑 c:\windows\system32\drivers\etc\hosts.................................................................................2
3.设置两个网卡 ip 地址...................................................................................................................3
4.配置共享磁盘................................................................................................................................3
5.安装另外个节点 2.......................................................................................................................11
6.启动两个节点后 看互相是否能 ping 通...................................................................................11
7.安装 clustware 集群软件 ............................................................................................................12
8. Install the Database Software and Create an ASM Instance .......................................................27
9.dbca 创建集群数据库 ................................................................................................................36
1.安装第一个节点 windows 2003 虚拟机
用 vmware 添加 5 块虚拟硬盘,
1,2 两块做 ocr 和 voting disk, 3,4,5 三块做 asm 存储,并且添加一块网卡
1.在虚拟机配置文件中 rac1.vmx 文件 加入以下内容 设定两节点可以
共享磁盘
disk.locking = "FALSE"
diskLib.dataCacheMaxSize = "0"
diskLib.dataCacheMaxReadAheadSize = "0"
diskLib.dataCacheMinReadAheadSize = "0"
diskLib.dataCachePageSize = "4096"
diskLib.maxUnsyncedWrites = "0"
scsi1.present = "TRUE"
scsi1.virtualDev = "lsilogic"
scsi1.sharedBus = "VIRTUAL"
scsi1:1.present = "TRUE"
scsi1:1.mode = "independent-persistent"
scsi1:1.fileName = "e:\shared\ocr.vmdk"
scsi1:1.deviceType = "Disk"
scsi1:1.redo = ""
scsi1:2.present = "TRUE"
scsi1:2.mode = "independent-persistent"
scsi1:2.fileName = "e:\shared\votingdisk.vmdk"
scsi1:2.deviceType = "Disk"
scsi1:2.redo = ""
scsi1:3.present = "TRUE"
scsi1:3.mode = "independent-persistent"
scsi1:3.fileName = "e:\shared\asm1.vmdk"
scsi1:3.deviceType = "Disk"
scsi1:3.redo = ""
scsi1:4.present = "TRUE"
scsi1:4.mode = "independent-persistent"
scsi1:4.fileName = "e:\shared\asm2.vmdk"
scsi1:4.deviceType = "plainDisk"
scsi1:4.redo = ""
scsi1:4.present = "TRUE"
scsi1:4.mode = "independent-persistent"
scsi1:4.fileName = "e:\shared\asm3.vmdk"
scsi1:4.deviceType = "Disk"
scsi1:4.redo = ""
2.编辑 c:\windows\system32\drivers\etc\hosts
加入以下内容
127.0.0.1 localhost
# Public
192.168.3.152 rac1.localdomain rac1
192.168.3.155 rac1.localdomain rac2
#Private
192.168.0.101 rac1-priv.localdomain rac1-priv
192.168.0.102 rac2-priv.localdomain rac2-priv
#Virtual
192.168.2.111 rac1-vip.localdomain rac1-vip
192.168.2.112 rac2-vip.localdomain rac2-vip
of 36
