CASE STUDY: UNDERSTANDING ERROR ORA-15196

This document provides an explanation of error ORA-15196, including the details

of each argument, suggestions for the diagnostic of the error and finally includes

a case study using a real problem reported by a customer.

Error Description

ORA-15196 is reported after a validation of an ASM metadata block has failed.

The error will be reported in the following format:

ORA-15196: invalid ASM block header [1st] [2nd] [3rd] [4th] [5th != 6th]

Where the arguments indicate:

Argument Meaning

Function and line number in the code, where the exception is raised

Field failing the validation

ASM object number stored in the block

ASM block number stored in the block

Value associated with field referenced by argument 2

6th Expected value for field referenced by argument 2

Example:

ORA-15196: invalid ASM block header [kfc.c:7997] [endian_kfbh] [1] [93] [211 != 0]

Function and line number in the code, where the exception is raised = kfc.c:7997

Field failing the validation = endian_kfbh

ASM object number stored in the block = 1

ASM block number stored in the block = 93

Value associated with field referenced by argument #2 = 211

Expected value for field referenced by argument #2 = 0

Arguments description

• Function and line number in the code, where the exception is raised

In general terms it is valid to say this argument will be the same in most of the

possible cases, because is always the same routine where this exception is

raised.

#define kfbValid(data, len, type, bl) \

kfbValidPriv(data, len, type, bl, __FILE__, __LINE__).

• Field failing the validation

The ASM metadata is composed by many different structures like file directory,

disk directory, active change directory (ACDC), etc, which are organized by files

(asm file# between 1 and 255). Each file will be made of extents, which will be

made of ASM block (4096 bytes). Each block has a generic block header (kfbh),

and any of those fields can be validated.

kfbh.endian: 0 ; 0x000: 0x00

kfbh.hard: 130 ; 0x001: 0x82

kfbh.type: 4 ; 0x002: KFBTYP_FILEDIR

kfbh.datfmt: 1 ; 0x003: 0x01

kfbh.block.blk: 80 ; 0x004: T=0 NUMB=0x50

kfbh.block.obj: 1 ; 0x008: TYPE=0x0 NUMB=0x1

kfbh.check: 4268948098 ; 0x00c: 0xfe72fa82

kfbh.fcn.base: 0 ; 0x010: 0x00000000

kfbh.fcn.wrap: 0 ; 0x014: 0x00000000

kfbh.spare1: 0 ; 0x018: 0x00000000

kfbh.spare2: 0 ; 0x01c: 0x00000000

A short description of each of the fields referenced above (file kf3.h):

kfbh.endian endianness of writer big or little endian

kfbh.hard H.A.R.D. magic # and block size

kfbh.type metadata block type (type of ASM metadata)

kfbh.datfmt metadata block data format

kfbh.block.blk block location of this block

kfbh.block.obj check value to verify consistency

kfbh.check change number of last change

kfbh.spare1 zero pad out to 32 bytes

kfbh.spare2 zero pad out to 32 bytes

A list of the fields reported by this error through different SR is:

endian_kfbh

obj_kfbl

hard_kfbh

type_kfbh

datfmt_kfbh
