Data Morphing: An Adaptive, Cache-Conscious Storage

Technique

Richard A. Hankins Jignesh M. Patel

University of Michigan

1301 Beal Avenue; Ann Arbor, MI 48109-2122; USA

{hankinsr, jignesh}@eecs.umich.edu

Abstract

The number of processor cache misses has a crit-

ical impact on the performance of DBMSs run-

ning on servers with large main-memory conﬁgu-

rations. In turn, the cache utilization of database

systems is highly dependent on the physical or-

ganization of the records in main-memory. A re-

cently proposed storage model, called PAX, was

shown to greatly improve the performance of se-

quential ﬁle-scan operations when compared to

the commonly implemented N-ary storage model.

However, the PAX storage model can also demon-

strate poor cache utilization for other common op-

erations, such as index scans. Under a workload

of heterogenous database operations, neither the

PAX storage model nor the N-ary storage model

is optimal.

In this paper, we propose a ﬂexible data stor-

age technique called Data Morphing. Using

Data Morphing, a cache-efﬁcient attribute layout,

called a partition, is ﬁrst determined through an

analysis of the query workload. This partition is

then used as a template for storing data in a cache-

efﬁcient way. We present two algorithms for com-

puting partitions, and also present a versatile stor-

age model that accommodates the dynamic reor-

ganization of the attributes in a ﬁle. Finally, we

experimentally demonstrate that the Data Morph-

ing technique provides a signiﬁcant performance

improvement over both the traditional N-ary stor-

age model and the PAX model.

Permission to copy without fee all or part of this material is granted pro-

vided that the copies are not made or distributed for direct commercial

advantage, the VLDB copyright notice and the title of the publication and

its date appear, and notice is given that copying is by permission of the

Very Large Data Base Endowment. To copy otherwise, or to republish,

requires a fee and/or special permission from the Endowment.

Proceedings of the 29th VLDB Conference,

Berlin, Germany, 2003

1 Introduction

Database systems have traditionally focused on improving

the overall system performance by minimizing the num-

ber of disk I/O operations. Disk I/O has traditionally been

the most important component of the memory access hi-

erarchy, but the current trend in Random Access Memory

(RAM) cost and capacity now makes it necessary to re-

evaluate this focus. The cost of RAM is decreasing rapidly,

while the capacity of RAM is increasing exponentially.

This trend was recognized by the authors of the Asilomar

report where they predicted that, in the future, all but the

largest data sets will reside entirely in main-memory [5].

As increasing amounts of data become main-memory res-

ident, the performance bottleneck becomes the accesses to

main-memory rather than the accesses to disk [7]. Because

of this shift, intelligently storing and accessing the data in

main-memory is becoming critical to the performance of

database systems [2, 7, 17, 22].

Unfortunately, the main-memory bottleneck is becom-

ing more severe due to the growing disparity between

processor speeds and the latency in accessing the main-

memory. To alleviate this disparity, modern processors em-

ploy a hierarchy of low-latency memory, called caches, that

reside between the processor and the RAM. Each cache

stores the most frequently accessed data blocks (includ-

ing instructions), reducing the amount of data that must be

retrieved directly from the main-memory. Starting at the

ﬁrst level of cache memory, each subsequent level of cache

stores larger amounts of data, but each subsequent level of

cache is also more expensive to access. Modern processors

typically contain two, or even three, levels of processor

cache, with each level storing both instructions and data.

Research has shown that database systems incur a signif-

icant amount of second level (L2) data cache misses, and

consequently, the L2 cache utilization is critical to overall

performance [3]. In this paper we only focus on techniques

for reducing the L2 cache misses, and simply refer to them

as cache misses for the remainder of this paper.

Critical to system performance is the efﬁcient retrieval

and update of data records inside the database. Database

systems typically store records of data in ﬁles, where each

ﬁle consists of a collection of slotted-pages, and each

slotted-page contains a collection of records. A page is

a ﬁxed-size block of allocated memory. A slotted-page is

a page that contains an array of byte-offsets that reference

the start of each record allocated within the page. Typi-

cally, each attribute of the record is stored in consecutive

memory addresses on the slotted page, in what is called the

N-ary storage model. Common implementations of the N-

ary storage model place variable length attributes at the end

of the ﬁxed-length attributes, and use ﬁxed length place-

holders to reference the relocated attributes.

A recently proposed storage model, called PAX, ver-

tically decomposes each record, storing each attribute in

subdivisions of a page, called mini-pages [2]. The PAX

storage model improves the cache utilization for queries

that access only a few attributes from a high percentage

of records, such as during a sequential ﬁle scan. This im-

provement in cache utilization is a direct result of being

able to pack attributes of many different records into the

same cache line. However, for access plans where only a

fraction of the records are accessed, such as during an index

scan, the PAX storage model can result in a greater number

of cache misses. In such cases, N-ary may actually perform

better, especially as the number of attributes accessed per

record increases.

As previously demonstrated, both the N-ary and the

PAX storage models work well for different families of ac-

cess plans. A choice between the two storage models is dif-

ﬁcult as the query workload may be large or may vary over

time. A better storage model should incorporate the best

characteristics of both models; namely, vertical decompo-

sition and groups of sequentially allocated attributes. This

storage model should also provide the ﬂexibility to adapt to

changing workloads. In this paper, we propose a novel data

storage technique, called Data Morphing (DM) that meets

these goals.

This paper makes the following contributions:

• We present a ﬂexible page architecture that is a gener-

alization of the previously proposed PAX page architec-

ture. In the Data Morphing page architecture, attributes

of the same tuple can be stored in non-contiguous groups,

which increases the spatial locality of memory accesses.

As a result, fewer cache misses are incurred during query

processing.

• We present two algorithms for calculating the attribute

groups that are stored on each page. The Naive algo-

rithm performs an exhaustive search of the possible at-

tribute layouts, but the algorithm is expensive to compute

for relations with a large number of attributes. The Hill-

Climb algorithm performs a greedy search of the layout

space, trading optimality for faster time complexity.

• We present an empirical evaluation of the Data Morphing

technique. We show that the partitioning algorithms cal-

culate attribute groupings that reduce the number of cache

misses incurred during query execution. As a direct result

of improving the cache utilization, our prototype DBMS

implementing the DM technique can evaluate queries up

to 45% faster than the N-ary storage model and up to 25%

faster than the PAX model.

The remainder of this paper is organized as follows:

Section 2 presents an example motivating the need for Data

Morphing. Section 3 provides deﬁnitions for the common

terms used in the subsequent sections. In Section 4, we

present the Data Morphing technique. A detailed experi-

mental evaluation is presented in Section 5. Related work

is discussed in Section 6, and Section 7 contains our con-

clusions.

2 Motivating Example

As described in the introduction, neither the N-ary storage

model nor the PAX storage model provide the optimal stor-

age model for data. To illustrate this fact, we will use the

relation and query shown in Figure 1 in the following ex-

ample.

Client (id:Integer,priority:Integer,name: Varchar(32),

usage: Real, address: Varchar(32),

location: Integer) key (id);

SELECT location, usage

FROM Client WHERE priority < 12

Figure 1: Client Relation and Query

In Figure 1, the Client relation consists of six at-

tributes of types Integer, Real, and Varchar. The Integer and

Real data types are each four bytes in size. The Varchar(32)

data type is a variable length string with a maximum length

of 32 bytes. The selectivity of the predicate on priority

is 12.5%, and the processor cache line size is 32 bytes. Fig-

ure 2 shows a single record in the Client relation as it is

stored on a page using the N-ary storage model; as in typ-

ical implementations, the variable-length strings are stored

at the end of the ﬁxed-length attributes. To visualize the at-

tributes that are read into the processor cache as the result

of a cache miss, the width of the diagram is shown to be the

same size as a cache line.

Assuming that a sequential ﬁle scan is used to answer

this query, the records are retrieved as follows. The ﬁrst

priority attribute is requested from memory. This

memory access incurs a cache miss to read the contigu-

ous block of memory containing the attribute into the pro-

cessor cache. If the v alue of the priority attribute is

less than 12,thelocation and usage attributes are ac-

cessed. Because the location and usage attributes are

contained in the processor cache, retrieving them incurs no

additional cache misses. The select operator then continues

with the next record, until all of the records have been read.

The cost of answering this query totals approximately one

cache miss per record.

The PAX storage model vertically decomposes the

records into zones, called mini-pages, as shown in Fig-

ure 3; for simplicity, we do not show all of the details.

In the ﬁgure, the attributes are presented as belonging
